Powerex, Inc., 200 Hillis Street, Youngwood, Pennsylvania 15697-1800 (724) 925-7272
CSD3120H, CSD3160H
Single SCR POW-R-BLOK? Modules
400 Amperes/1200-1600 Volts
Absolute Maximum Ratings
Characteristics
Peak Forward Blocking Voltage
Transient Peak Forward Blocking Voltage (Non-Repetitive) t < 5ms
DC Forward Blocking Voltage
Peak Reverse Blocking Voltage
Transient Peak Reverse Blocking Voltage (Non-Repetitive), t < 5ms
DC Reverse Blocking Voltage
RMS On-State Current
Average On-State Current, TC = 66°C
Peak One-Cycle Surge (Non-Repetitive) On-State Current (60Hz)
Peak One-Cycle Surge (Non-Repetitive) On-State Current (50Hz)
I2t (for Fusing), 8.3 milliseconds
Critical Rate-Of-Rise of On-State Current*
Peak Gate Power Dissipation
Average Gate Power Dissipation
Peak Forward Gate Voltage
Peak Reverse Gate Voltage
Peak Forward Gate Current
Storage Temperature
Operating Temperature
Maximum Mounting Torque M5 Mounting Screw
Maximum Mounting Torque M8 Terminal Screw
Module Weight (Typical)
V Isolation
Symbol
VDRM
VDSM
VD(DC)
VRRM
VRSM
VR(DC)
IT(RMS)
IT(AV)
ITSM
ITSM
I2t
di/dt
PGM
PG(AV)
VGFM
VGRM
IGFM
TSTG
Tj
—
—
—
VRMS
CSD3120H
1200
1350
960
1200
1350
960
620
400
8000
7300
267,000
100
10
3
10
5.0
4.0
-40 to 125
-40 to 125
17
72
450
2500
CSD3160H
1600
1700
1280
1600
1700
1280
620
400
8000
7300
267,000
100
10
3
10
5.0
4.0
-40 to 125
-40 to 125
17
72
450
2500
Units
Volts
Volts
Volts
Volts
Volts
Volts
Amperes
Amperes
Amperes
Amperes
A2sec
Amperes/ s
Watts
Watts
Volts
Volts
Amperes
°C
°C
in.-lb.
in.-lb.
Grams
Volts
*Tj = 125°C, IG = 1.0A, VD = 1/2 VDRM
S-6
